Allen Bradley brand 1606-XLP15E Power Supply
-
Power Supply, 15 W, 24V DC
-
No Special Function
-
Compact Family
-
Global Input Voltage
Product Description
Technical Specifications
Mechanical
| Height | 75 mm |
| Depth | 91 mm |
| Direct mounting possible | No |
| Width | 22.5 mm |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Screw connection |
| Shock | 30 G, 6 ms 20G, 11 ms |
| Special functions | No special function |
| MTBF | 4369000 hours @ 40 °C, SN 29500 |
| Wall mounting possible | Yes |
| Degree of protection (NEMA) | Other |
| Vibration | 2 G |
Electrical
| Secondary voltage adjustable | Yes |
| Power output | 15 W |
| Voltage type of supply voltage | AC/DC |
| Rated supply voltage at DC | 85 V |
| Efficiency, typ | 85.1 % |
| Adjustment range | 24 V |
| Operational range | 85...264V AC |
| Rated output current | 0.54 to 0.63 A |
| Phases | 1-phase |
| Sub group | Compact family |
| Hold-up time | >47 ms @ 100V AC |
| Input voltage | 100…240V AC |
| Special family function | No power boost |
| Rated input current | <0.28 A @ 100V AC |
| Special feature | — |
| Output voltage stabilized | Yes |
| Rail mounting possible | Yes |
| Stabilized | Yes |
Environmental
| Ripple and noise, max | 50 mV |
| Operating temperature | -10 °C |
| Storage temperature | -40 °C |
| Relative humidity | 5 to 95 % |
Construction
| Weight | 130 g |
