Allen Bradley brand 1606-XLE80E Power Supply, 80 W, 24V DC
-
Power Supply
-
80 W, 24V DC
-
No Special Function
-
Essential Line
Product Description
Technical Specifications
Electrical
| Nominal value output voltage 1 | 24 V |
| Secondary voltage adjustable | Yes |
| Max. output current 1 | 3.3 A |
| Nominal value output current 1 | 3.3 A |
| Power output | 80 W |
| Voltage type of supply voltage | AC/DC |
| 1st secondary output voltage | 24 V |
| Rated supply voltage at AC 50 Hz | 100 V |
| Rated supply voltage at AC 60 Hz | 100 V |
| Rated supply voltage at DC | 110 V |
| Derating | 1.8 W/°C |
| Input inrush current limiter | NTC |
| Adjustment range | 24 V |
| Power factor | 0.56 typical |
| Operational range | 90…132V AC |
| Rated output current | 3.3 A, 24V |
| External input fuse, min | B-10 A or C-6 A |
| Power losses | 9.1 W typical |
| Sub group | Essential line |
| Hold-up time | >60 ms @ 120V |
| Efficiency | 89.8% typical |
| Input inrush current | 23 A/45 A |
| Special family function | Dynamic 120% power boost under 45C Degree |
| Rated input current | 1.24 A, 100V AC |
| Special feature | NEC Class 2 |
| Output voltage stabilized | Yes |
| Rail mounting possible | Yes |
| Stabilized | Yes |
Mechanical
| Height | 124 mm |
| Depth | 102 mm |
| Direct mounting possible | No |
| Width | 32 mm |
| Degree of protection (IP) | IP20 |
| Type of electric connection | Screw connection |
| Shock | 30 G, 6ms 20 G, 11ms |
| MTBF | 2243 kh (40 °C, SN29500) |
| Wall mounting possible | Yes |
| Vibration | 2 G |
Environmental
| Ripple and noise, max | 50 mV |
| Operating temperature | -25 °C |
| Storage temperature | -25 °C |
| Lifetime, min | 77 kh (+40 °C) |
| Relative humidity | 5 to 95 % |
Construction
| Weight | 430 g |
